1. Intelligent pressure vibration system
Adopting the fifth-generation servo hydraulic vibration technology, the vibration frequency is adjustable from 0 to
4500
times/minute
Pressure control accuracy is ±0.3Bar, ensuring that the density uniformity of the brick body reaches more than
98%
Equipped with automatic compensation system to adapt to raw materials of different consistencies
2. Digital control platform
Siemens S7-1200 PLC control system
10.4-inch industrial touch screen, supporting 12 language interfaces
Can store 200+ production formulas, one-click switch product type
3. Energy-saving and environmentally friendly design
The whole Cement Brick Making Machine power is only 45kW, and the energy consumption is 30% lower than that of traditional equipment
Enclosed noise reduction structure, working noise ≤72dB
Industrial wastewater recycling system
4. Modular structure
The core components are made of chromium-molybdenum alloy steel, with a service life of more than 10 years
Quick-change mold system (replacement time <15 minutes)
Optional robot automatic stacking system
1.
Construction engineering field: used to produce hollow bricks, solid bricks, and masonry building walls. Their
good
strength provides a stable framework for the building. At the same time, their thermal insulation performance
can
improve living comfort. They are indispensable material production equipment in construction.
2. Municipal
construction field: They can manufacture neat and durable curbstones for paving the edges of roads,
standardizing
road boundaries, and ensuring road traffic safety; they can also produce other cement brick products that meet
municipal needs, such as sidewalk bricks, etc., to provide high-quality materials for urban infrastructure
construction and improve the beauty and practicality of urban roads.
3. Garden landscape field: The special cement
bricks produced can be used to pave garden trails and construct landscape sketches. With their excellent
stability,
they can withstand the test of long-term outdoor environments, add unique style to gardens, and help create
garden
landscapes that are both artistic and practical. Whether it is indoor factory production or outdoor open-air
operations, the German Zenith 913 cement brick machine can stably supply high-quality cement brick products to
various industries and promote the efficient implementation of projects.
Technical Data
| Features | |
| Hopper volume | 1,000L |
| Max.feeding height of the loader | 2,005L |
| Max forming length | 1,240mm |
| Max.foming width | 1,130mm |
| Min product height | 175mm |
| Max. product height | 330mm |
| Weight | |
| Including mould and vibration motor | 5T |
| Size | |
| Total lengthi | 2,850mm |
| Total height | 3,000mm |
| Total width | 2,337mm |
| Vibration system | |
| Max exciting force of vibration table | 48KN |
| Max.exciting force of upper vibration | 20KN |
| Energy consumption | |
| With maximum numbers of vibration motor | 16KW |
Production Capacity
| Block Type | Dimension(mm) | Pictures | Qty/Cycle | Cycle Time | Production Capacity(Per 8hs) |
| Hollow Block | 400*200*200 |
|
12 | 35s | 9,792pcs |
| 400*150*200 | 16 | 35s | 13,165pcs | ||
| 520*160*200 | 12 | 35s | 9,792pcs | ||
| Soild Block | 225*112.5*80 |
|
12 | 35s | 9,792pcs |
