1. Intelligent production system: equipped with AI visual detection and adaptive adjustment functions, real-time optimization of production process parameters
2. Ultra-high efficiency: equipped with a dual vibration table synchronous working system, production capacity increased by 30%, daily output reached 15,000 standard bricks
3. Energy saving and environmental protection: innovative energy recovery device, energy consumption reduced by 25% compared with traditional equipment
4. Intelligent maintenance: predictive maintenance system can warn of potential failures in advance, and equipment utilization rate increased to 95%
1. New urbanization construction
Intelligent ecological bricks: integrated permeable and water purification functions to create sponge city infrastructure
Modular paving system: fast assembly of municipal roads and square pavements
2. Green building revolution
3D printing building components: precise production of special-shaped blocks, assisting parametric building design
Zero-carbon building bricks: using solid waste raw materials, carbon footprint reduced by 40%
Technical Data
| Maximum Forming Area | 1,300*650mm |
| Block Height | 40-300mm |
| Cycle Time | 14-24s (depending on block type) |
| Servo Vibration Force | 100KN |
| Pallet Size | 1,350*700*（14—35）mm |
| Servo Vibration Motors in Bottom | 2*12KW/Set |
| Top Vibration Motors on Tamper Head | 2*0.55KW |
| Control System | SIEMENS |
| Total Power | 52.6KW |
| Total Weight | 17T (including facemix device &mould) |
| Machine Dimension | 6,300×2,800×3,500mm |
Production Capacity
| Block Type | Dimension(mm) | Pictures | Qty/Cycle |
Production Capacity (Per 8hs) |
| Hollow Block | 390*190*190 |
|
9 | 10,800-13,500pcs |
| Rectangular Paver | 200*100*60-80 |
|
36 | 43,200-50,400pcs |
| Interlocks | 225*112,5*60-80 |
|
25 | 30,000-37,500pcs |
| Curstone | 500*150*300 |
|
4 | 4,800-5,600pcs |
