1. Intelligent pressure vibration system
Adopting the eighth generation multi-axis servo hydraulic vibration technology, the vibration frequency is 0-5500 times/minute steplessly adjustable
Pressure control accuracy ±0.2Bar, ensuring the clarity of brick texture and uniformity of density
Equipped with intelligent raw material compensation system, automatically adapting to aggregates with different particle gradings
2. Digital control center
Siemens S7-1500T PLC+17-inch industrial touch screen
Supports 20 language interfaces, 1000+ recipe storage capacity
3D visualization production process simulation system
3. Environmental protection and energy-saving design
The whole Imitation Stone Brick Machine power is only 95kW, and the energy consumption is 40% lower than that of traditional equipment
Fully enclosed noise reduction structure, working noise ≤68dB
Industrial dust collection rate ≥99.5%
4. Super durable structure
Integral hardened alloy steel frame, service life exceeds 15 years
Core hydraulic components are imported from Rexroth
Quick change mold system (replacement time <10 minutes)
HP-1200T Imitation stone brick machine is very useful. In the construction of municipal facilities, the imitation stone bricks produced by it can be used to pave urban sidewalks, square floors, etc., with realistic stone appearance and excellent performance, to improve the quality of urban landscape; in water conservancy projects, the hydraulic bricks produced can be used for river bank slope protection, dam reinforcement and other projects, to provide security for the safety and stability of water conservancy facilities. When creating garden landscapes, through secondary processing processes such as polishing, shot blasting, splitting, spraying, and aging, the imitation stone bricks produced can be further processed into imitation stone PC bricks, blind bricks, cultural stones, imitation ceramic tiles, antique bricks and other products, which are widely used in parks, scenic spots, courtyards and other places to create a natural and beautiful landscape atmosphere.
Five reasons to choose HP-1200T
German precision: All key components are inspected by German original factory
Texture fidelity: 98% natural stone simulation
Intelligent production: MES intelligent manufacturing system can be optionally equipped
Global service: Technical service centers are established in 60+ countries
Quick return: 12-18 months investment recovery period
Equipment parameters
| Model | HP-1200T |
| Number of Workstations | 7 |
| Brick-like arrangement (listing) | 900*900 (1 piece/board) |
| 500*500 (2 pieces/board) | |
| 400*400 (4 pieces/board) | |
| Maximum brick thickness | 80mm |
| Maximum main pressure | 1200t |
| Diameter of main pressure cylinder | 740mm |
| Weight (including one set of molds) | About 90,000kg |
| Power of main machine | 132.08KW |
| Cycle cycle | 12-18s |
| Length, width and height | 9000*7500*4000mm |
