German technology, extreme stability: full servo hydraulic drive system, precise and controllable pressure output, equipment operation stability increased by 40%, and mold life extended by 50%. Intelligent and efficient, excellent production capacity: equipped with industrial-grade PLC control system, supporting remote monitoring and fault diagnosis, single-shift production capacity can reach up to 5,000 standard blocks (depending on mold configuration), and production efficiency is leading in the industry. Energy saving and environmental protection, green benchmark: energy consumption is 25% lower than traditional models, noise is less than 75 decibels, dust collection efficiency is 98%, in line with the German TÜV environmental certification standards. One Cement Block Molding Machine for multiple uses, flexible production: the modular mold system can quickly switch to produce more than 15 types of products, complete mold replacement within 10 minutes, and adapt to small batch customized production needs.
1. Large-scale infrastructure and municipal engineering
In the infrastructure boom of countries along the "Belt and Road", QT6 has become the preferred equipment for
highway slope protection bricks, municipal drainage ditch covers and other projects with its ultra-high production
capacity and product consistency, helping contractors shorten construction periods by more than 30%.
2. Green building and prefabricated development
Aiming at the European and American LEED certification and China's green building three-star standard, QT6 can
produce lightweight and high-strength insulation blocks, helping prefabricated construction companies break through
the technical bottleneck of environmentally friendly building materials.
3. Venture capital in emerging markets
In Southeast Asia, the Middle East and other regions, its "low investment-high return" characteristics (payback in
as fast as 8 months) and localized technical service network are driving small and medium-sized investors to
establish regional building materials production bases.
4. Special construction of sponge cities
The original permeable brick production process meets the needs of China's "sponge city" construction. The
permeability of the road bricks produced can reach 1.5×10-2cm/s, effectively solving the problem of urban
waterlogging.
• The world's first "double vibration + hydraulic pressing" composite process, the product density increased by 15%
• The intelligent lubrication system extends the maintenance cycle of key components to 2,000 hours
• Optional AI quality inspection module, real-time elimination of defective products, and the scrap rate is
controlled below 0.3%
Zenit QT6 not only redefines the performance boundary of block production equipment, but also represents the deep
integration of German Industry 4.0 and the construction industry. Choosing QT6 means choosing:
5 tons of raw material conversion efficiency per hour
Millimeter-level dimensional accuracy for each brick
Maximum utilization value of each kilowatt-hour of electricity
Let German precision become your core competitiveness in the global building materials market.
Technical Data
| Moulding Cycle | 15-30s |
| Vibration Force | 60KN |
| Motor Frequency | 50-60HZ |
| Total Power | 31KW |
| Total Weight | 7.5T |
| Machine Size |
8,100*4,450*3,000 mm (without face device) 9,600*4,450*3,000mm(with face device) |
Production Capacity
| Block Type | Dimension(mm) | Pictures | Qty/Cycle |
Production Capacity (Per 8hs) |
| Hollow Block | 400*200*200 |
|
6 | 6,600-8,400 |
| Rectangular Paver | 200*100*60 |
|
21 | 23,000-29,400 |
| Paver | 225*112,5*60 |
|
15 | 16,500-21,000 |
| Curstone | 500*150*300 |
|
2 | 2,200-2,800 |
